Description
QII-Classic
This is a faithful reproduction of the original mono amplifier – the new QUAD II Classic offers audiophiles the chance to recreate the spirit and atmosphere produced by one of the most famous amplifiers in audio history.
Peter’s circuit – most notably the design of the output transformer – has become of legendary status, and analysed endlessly by some of the finest minds in the audio industry.
The QUAD II Classic has been recreated accurately with output valves and input valves the equivalent of those used in the original.
The output valves produce around 15W per channel operating in Class A, which allow a gloriously sweet and refined sound with appropriately matched contemporary loudspeakers. The QII Mono is available and supplied in matched pairs.
Features
- Faithful reproduction of the classic valve mono amplifier.
- Delivering 15W per-channel into 8 Ohms.
- Sweet, warm, refined valve sound.
Specifications
- Model: QII-Classic
- Input Sensitivity: 775 mV RMS
- Power Output: 15 W RMS
- Output Impedance: 8 Ohms
- THD @ 700 Hz: 0.8 % @ 12 W
- Residual Hum / Noise: Better than -90 dB
- Frequency Response: 10 Hz – 20 kHz (± 0.2 dB)
- Damping Factor: 11.75 @ 700 Hz (referred to 8 Ohms)
- Valves: 2 x EF86, 2 x KT66, 1 x GZ34
- Dimensions (W x H x D): 335 x 121 x 171 mm
- Weight: 8.3 kg
Full Quad Range Available
Unilet Sound & Vision are official retail partners for Quad Audio, providing sales, advice and assistance on their entire range of high-quality products. Please do get in touch if you would like a demonstration or wish to purchase.
